Topglass® GC SPF Hybrid
Topglass® GC SPF Hybrid
Climatex System with SPF Hybrid Solar Protection Reduces Heat by 79%
One common issue with skylight roofs is the increased heat load they introduce, leading to unnecessary heat transfer into the property. This results in higher energy consumption as more electricity is needed to cool the building. Topglass® GC SPF Hybrid translucent sheets address this problem effectively by providing excellent solar control, reflecting UV rays and preventing excessive heat from penetrating the building.
- Decreases heat gain by nearly 79% compared to standard fiberglass
- Reflects solar transmission by almost 100% compared to standard fiberglass
- Reduces energy costs
- Durable Climatex System with 130 microns gelcoat and film coating
- 30 years water penetration warranty
- 25 years light transmission warranty
- 25 years non-fiber show warranty
- Exhibits solar reflection capability nearly double that of standard fiberglass roof sheets
- Reduces total heat gain by almost 79% compared to standard fiberglass roof sheets
- Maximizes visible light transmission while blocking unwanted solar transmission into the building
- Lowers energy and air conditioning costs, reducing the need for additional artificial lighting
- Virtually eliminates harmful UVB rays from entering the building
Applications
- Air-conditioned buildings such as supermarkets and malls
- Food processing facilities
- Warehouses and retail outlets storing food and fresh produce
- Bulk paper storage areas
- Temperature-sensitive environments requiring ample natural lighting
- Barcol Hardness (Barcol Impressor Model no.GYZJ.934)
- Exposure Ultraviolet lamps M/C (Compile AS/NZS 2433)
- Spectrophotometer (Model no. CM-3600A for measurement L,A,B)
- Diffuse Light Tranmission M/C (AS/NZS 4257.4)
- Impact Resistant M/C (Compile AS/NZS 4257.6)
- QUV Accelerated Weathering Chamber UVB313 (ASTM G53)
- Microscope Camera
Raw Material
- Utilizing high-quality resin and incorporating UV Absorber Plus (UVAS+), a substance produced with nanotechnology, helps absorb UV radiation effectively, preventing it from passing through the underside of the sheet surface.
Top Coating
- EXO-SET 205, a high-quality gel coating layer produced with advanced technology from New Zealand, has a thickness of 100 microns to effectively protect against UV radiation. It is combined with a Solar Protective Coating to reflect heat and prevent it from entering the building.
Fiberglass
- High quality fiberglass strands are used to enhance the strength of translucent sheets, ensuring long-lasting durability and resistance to cracks, shrinkages and water leakages.
Bottom Film
- Our final translucent sheet product using CHP Production Technology will result in a fully cured product. Hence the bottom film is no longer required and will be removed to prevent delamination.
Production Process
- Our production process utilizes advanced CHP (Cumene Hydroperoxide) technology, which operates at higher temperatures and incorporates a longer production line compared to the traditional MEKP method. As a result, our product is fully cured and highly durable.
Thickness / Weight
- Thickness = 1.5 mm.
- Weight = 2400 gsm.
 |
| Color : SPF Hybrid |
| Visible Light Transmittance = 11.8% Diffuse Light Transmission = 44% |
- Received AS/NZS 4256.3:2006 standard, Client BMP NO. 535535, a standard from Australia, acknowledged in over 90 countries worldwide.
- Certified for manufacturing quality by BSI Group from Australia, an organization certifying product standards accepted in 150 countries worldwide.
- Received the Thai Industrial Standard, TIS 612-2549, from Thailand.
 |
 |
 |
 |
 |
